Precision Alloy Pipe&Tube, please note that the above table provides a range of standard thicknesses, widths, and lengths for Precision Alloy.
- Dimensions:
- Outside Diameter: Φ6 – Φ200mm
- Wall Thickness: 0.35 – 60mm
- Length: ≤ 12000mm
- Certification: ISO, SGS, BV and so on.
- *Customized size needs to be confirmed with us
- Shapes: Angle, Hexagon, Square, Channel, Round,etc.
- Grades: 1J22 soft magnetic alloy, 1J50 soft magnetic alloy, 1J79 Permalloy, 1J85 Permalloy, 4J32(Super-Invar), 4J36, 4J29Kovar alloy, 4J42Kovar alloy, Cobalt-based elastic alloy 3J21, 6026, 6J22, 50HXC.
Precision Alloy Pipe Size And Specifications
Huaxiao Metal Supplier provides all sizes of Precision alloy pipe for sale. Customized specifications are available upon request. Additionally, the exact chemical composition and mechanical properties may vary slightly within the ranges listed, depending on the specific alloy formulation and production process. Custom sizes are also available upon request. Welcome to inquire, and learn about more details about the alloy pipe.
| Alloy Type | Main Chemical Composition | Key Physical Properties | Typical Applications | Specifications |
|---|---|---|---|---|
| 1J22 | – | High saturation magnetic induction | Electromagnetic iron core, telephone headset diaphragm, torque motor rotor | Cold-rolled strip: Thickness 0.05~1.00mm, Width 60~120mm; Cold-drawn wire: Diameter 0.10~6.00mm; Hot-rolled flat: Thickness 6.0~12.0mm, Length ≥1000mm; Hot-forged bar: Diameter 20.0~100.0mm, Length ≥250mm or 150mm |
| 1J50 | Fe (80%90%), Si (3%5%), Al (≤1%), Trace Ni, Cu, Mo | High permeability, Low coercivity | Transformers, current transformers, inductors, motors, generators, high-frequency communication equipment, etc. | Cold-rolled strip: Thickness 0.03~3.5mm, Width 10~250mm; Cold-drawn wire: Diameter 0.10~6.00mm; Hot-rolled flat: 4.50~20.0×50~250mm; Hot-rolled (forged) bar: Diameter 5.0~180.0mm; Hot-rolled (forged) plate: Thickness 3.5~40.0mm; Cold-drawn tube, Cold-drawn capillary tube, etc. |
| 1J79 (Permalloy) | Ni (78.5~80%), Fe (13.73~16.8%), Mo (3.8~4.1%), Trace C, Si, Mn, S, P, Ti, Al, Cu | High permeability, Low coercivity in weak magnetic fields | Small transformers, chokes, relays, magnetic amplifiers, magnetic shields, etc. | Cold-rolled strip, Cold-drawn wire, etc. (specific specifications can be customized based on demand) |
| 1J85 | – | High saturation magnetic induction, Low hysteresis loss, High permeability, Excellent thermal stability | – | Wire, strip, bar, plate, tube, etc. (specific specifications such as cold-rolled strip/flat: 0.0383×1250mm; hot-rolled plate: 2.5100×1003000mm; hot-forged bar: Φ10400×5007000mm, etc.) |
Please note that the above specifications are typical and may vary slightly based on the manufacturer, production batch, and specific application requirements. For precise specifications and availability, it is recommended to consult with a supplier or manufacturer of Precision alloy pipes. Huaxiao Metal Manufacturer also provides other shapes of Precision products, such as strip, sheet&plate, coil, bar, wire&mesh. The price is affordable and suitable.
What are the Benefits?
Precision Alloy Pipe offers a multitude of benefits that make it an ideal choice for a wide range of applications. Precision Alloy Pipe offers a combination of high precision, enhanced mechanical properties, corrosion resistance, high temperature resistance, customizability, improved efficiency and reliability, and a wide range of applications. These benefits make it an ideal choice for a variety of demanding applications across multiple industries.Welcome to Huaxiao Metal Manufacturer to request the price, trust you can be satisfied in the alloy products and buy our products in quickly. Our services are in providing comprehensive and support to clients.
Precision Alloy Pipe Applications and Uses
Huaxiao Metal Supplier provides all kinds of precision alloy pipe in the world. Welcome to inquiry and ask for the price.
Electronic and Electrical Industry
Precision Alloy Pipe is also essential in the electronic and electrical industry. It is used to manufacture components such as transformers, inductors, and magnetic shielding devices due to its high magnetic permeability and low coercivity. These properties make it ideal for applications requiring precise magnetic field control.
Medical Equipment
In the medical equipment industry, Precision Alloy Pipe is used to manufacture precision instruments and equipment, such as MRI machines and X-ray tubes. The high precision and corrosion resistance of the alloy ensure the accuracy and reliability of these medical devices.
Other Industrial Applications
In addition, Precision Alloy Pipe is also used in the chemical industry, nuclear industry, and marine engineering due to its resistance to high temperatures, pressures, and corrosion. It is ideal for applications in harsh environments where traditional materials may fail.
Precision Alloy Pipe Advantages
High Precision and Accuracy
- Precision Alloy Pipe is manufactured to precise specifications, ensuring high dimensional accuracy and surface finish.
- This high precision allows for seamless integration into complex systems and reduces the need for additional machining or finishing processes.
Enhanced Mechanical Properties
- Precision Alloy Pipe exhibits excellent mechanical properties, such as high strength, toughness, and ductility.
- These properties make it suitable for applications that require high levels of stress and strain resistance.
Corrosion Resistance
- Many precision alloy pipes are formulated to resist corrosion, making them ideal for use in harsh environments.
- This corrosion resistance extends the lifespan of the pipe and reduces the need for maintenance and repairs.
High Temperature Resistance
- Precision Alloy Pipe can withstand high temperatures without significant degradation in performance.
- This makes it suitable for applications in high-temperature environments, such as in industrial furnaces, boilers, and engines.
Customizability
- Precision Alloy Pipe can be customized to meet specific requirements in terms of alloy composition, dimensions, and surface finish.
- This customizability allows for tailored solutions that meet the unique needs of each application.
Improved Efficiency and Reliability
- The precision and accuracy of Precision Alloy Pipe contribute to improved efficiency and reliability in various systems.
- This can lead to reduced downtime, increased productivity, and lower maintenance costs.
Alloy Factory
Huaxiao Metal Supplier provides professional services and reasonable prices, offering customers the best quality products. The Precision Alloy Pipe Alloy Factory is a specialized manufacturing facility dedicated to the production of high-quality precision alloy bars. This factory combines advanced technology, rigorous quality control, and experienced personnel to ensure the production of precision alloy pipes that meet the highest standards.The factory is equipped with state-of-the-art production equipment and machinery, capable of producing precision alloy pipes with precise dimensions and consistent quality. Welcome to require, and ask to the price.
You ask, we answer
We can provide small precision alloy pipe samples for you to check the quality. The sample is free, you only need to pay the shipping cost.
Precision alloy and titanium differ in composition, properties, and applications. Precision alloy is a specialized type of alloy material with various physical properties tailored for specific applications, while titanium is a lightweight, strong, corrosion-resistant metal widely used in aerospace, medical, and marine applications.
Precision alloy is a type of specialty alloy material that is engineered to exhibit precise and predictable physical properties. These alloys are designed for applications that require tight control over certain characteristics, such as magnetic, electrical, thermal, or mechanical properties.
