Incoloy 925 Bar, please note that the below table provides a range of standard thicknesses, widths, and lengths for Incoloy Alloy Bar.
- Dimensions:
- Outside Diameter: 6-2500mm
- Length: 2000mm, 2500mm, 3000mm, 5800mm, 6000mm, 12000mm, etc
- Shapes: Angle, Hexagon, Square, Channel, Round, Flat etc.
- Finish: Bright, Polishing, Mirror, Hairline, Pickled, Peeled, Black
- *Customized size needs to be confirmed with us
- Grades: 800, 800H, 800HT, 803, 825, 832, 864, 890, 903, 907, 908, 909, 925, 926, 945, 945X, MA956, A-286, 020, 028,DS, 330, 25-6HN, 27-7MO.
Incoloy 925 Bar Size And Specifications
Incoloy 925 is a nickel-based alloy with additions of molybdenum, copper, and titanium, designed to provide exceptional resistance to corrosion in a wide range of environments, including acidic and alkaline conditions.Incoloy 925 Bar is a premium-quality, precipitation-hardening nickel-iron-chromium alloy bar renowned for its superior mechanical properties, outstanding corrosion resistance, and excellent fabricability. This alloy, with its unique chemical composition and advanced processing techniques, finds extensive applications across various industries such as aerospace, marine engineering, petrochemicals, and more. Our company has the good service and delievery in China.
Incoloy 925 Bar is standardized under various international designations to ensure consistency and quality across global markets. Key standards include:
| Country | Standard Code/Number |
|---|---|
| United States | UNS N09925 |
| Europe | EN 2.4852 |
| China | GB 0Cr22Ni42Mo3Cu2Ti2AlNb |
These standard codes and numbers are used to identify and classify the material according to its composition, properties, and intended applications in the respective regions. It’s important to note that the specific coding system may vary slightly depending on the region and the organization issuing the standards.
Incoloy 925 Bar is a nickel-based high-temperature alloy strip widely used in high-temperature and corrosive environments, particularly suitable for high-temperature equipment in the petrochemical, power, metallurgical, and aerospace industries. Huaxiao Metal Supplier provides all sizes of incoloy alloy strip for sale. Customized specifications are available upon request. Additionally, the exact chemical composition and mechanical properties may vary slightly within the ranges listed, depending on the specific alloy formulation and production process. Custom sizes are also available upon request. Welcome to inquire and ask for the lastest price, and learn about more details about the alloy strips. As a leading supplier & manufacturer in China, Huaxiao Metal supply cost-effective Incoloy 925 Products.
Incoloy 925 Bar Chemical Composition
Huaxiao Metal Manufacturer has the professional experts in alloy, and offer the free service for every customers. The chemical composition of Incoloy 925 Bar is meticulously formulated to ensure its exceptional performance. The key elements and their respective ranges are listed in the table below:
| Element | Content Range (%) |
|---|---|
| Nickel (Ni) | 42.0 – 46.0 |
| Chromium (Cr) | 19.5 – 23.5 |
| Iron (Fe) | Balance |
| Molybdenum (Mo) | 2.5 – 3.5 |
| Copper (Cu) | 1.5 – 3.0 |
| Titanium (Ti) | 1.9 – 2.4 |
| Aluminum (Al) | 0.1 – 0.5 |
| Manganese (Mn) | ≤ 1.00 |
| Silicon (Si) | ≤ 0.50 |
| Niobium (Nb) | ≤ 0.50 |
| Carbon (C) | ≤ 0.03 |
| Sulfur (S) | ≤ 0.03 |
Incoloy 925 Bar Physical Properties
Incoloy 925 exhibits a range of physical properties that make it suitable for demanding applications:
| Property | Value |
|---|---|
| Density | 8.14 g/cm³ |
| Melting Range | 1350 – 1400 °C |
| Thermal Expansion Coefficient | 13.7 µm/m°C (20-100°C) |
| Thermal Conductivity | 11.4 W/m·K |
| Electrical Resistivity | 1.12 µΩ·m |
- Density: Approximately 8.14 g/cm³
- Melting Point: Approximately 1343°C (2451°F)
- Thermal Conductivity: Approximately 14.2 W/m·K at room temperature
- Specific Heat Capacity: Approximately 481 J/(kg·K) at room temperature
- Thermal Expansion Coefficient: Approximately 13.2 x 10⁻⁶/K over the range of 20 – 100°C
Huaxiao Metal Manufacturer has the good service and alloy and provides the solutions.
Incoloy 925 Bar Nickel-Based Alloy Mechanical Properties
The mechanical properties of Incoloy 925 bars are impressive, especially in high-stress environments:
| Property | Value |
|---|---|
| Tensile Strength | ≥ 690 MPa |
| Yield Strength | ≥ 310 MPa |
| Elongation | ≥ 30% |
| Hardness (Rockwell B) | ≤ 100 HRB |
Incoloy 925 Bar undergoes a series of heat treatments, such as solution treatment and aging treatment, to achieve optimal mechanical properties. Our company has the good alloy in China. After proper heat treatment, it offers the following mechanical properties:
- Tensile Strength: ≥ 725 MPa (105,000 psi)
- Yield Strength: ≥ 310 MPa (45,000 psi)
- Elongation: ≥ 30%
- Hardness: ≤ HRC 35
Huaxiao Metal Manufacturer also provides other shapes of Incoloy products, such as coil, plate&sheet, wire&mesh, tube&pipe, bar. The price is affordable and suitable. Welcome to inqiure and learn more details about incoloy.
Manufacturing Processes
Inconel 925 Bar is typically produced through sophisticated melting and casting processes, followed by heat treatment, forging, rolling, and other forming operations to achieve the desired microstructure and properties. Surface treatment processes may also be applied to further enhance its performance in specific applications.
Furthermore, Incoloy 925 Bar possesses excellent ductility, allowing it to be formed and shaped into various configurations without cracking or breaking. These mechanical properties, combined with its corrosion resistance and high-temperature stability, make Incoloy 925 Bar an ideal choice for applications in harsh environments such as the oil and gas, chemical, and nuclear industries. Huaxiao Metal Manufacturer is the professional and experienced in processing alloy in China, which has the good services and fast delivery in transportation.
What are the nickel-based alloy Benefits?
Incoloy 925 Bar, ensuring its suitability for high-temperature and corrosive environments. The material is widely used in industries such as chemical processing, power generation, and heat treatment due to its excellent oxidation resistance, carburization resistance, and thermal stability. Compliance with these standards guarantees consistent quality and performance across global applications.It is resistant to a variety of corrosive media, including those containing sulfur and chlorine, at high temperatures and pressures. Welcome to Huaxiao Metal Manufacturer to request the price, trust you can be satisfied in the alloy Premium incoloy products and other alloy in China. The service is good and offer solutions.
Incoloy 925 Bar Manufacturing Considerations
Huaxiao Metal Supplier provides all kinds of incoloy alloy coils in the world. Welcome to inquiry.
The production of Incoloy 925 bars involves several key steps:
Melting: The raw materials are melted in an electric arc furnace.
Refining: The molten metal is refined to achieve the desired chemical composition.
Casting: The refined metal is cast into billets or ingots.
Hot Working: The billets are hot rolled or forged into bars.
Heat Treatment: The bars undergo solution annealing to optimize mechanical properties.
Finishing: The bars are machined, polished, and inspected to meet specifications.
Incoloy 925 Bar Advantages and Characristics
Advantages and Benefits
High Strength: Incoloy 925 maintains high strength even at elevated temperatures.
Corrosion Resistance: Excellent resistance to a wide range of corrosive environments, including sour gas environments.
Weldability: Good weldability with standard welding techniques.
Fatigue Resistance: High resistance to fatigue and stress corrosion cracking.
Characteristics
High Temperature Performance: Suitable for use in environments up to 700°C.
Versatility: Can be used in a variety of industrial applications due to its balanced properties.
Longevity: Provides long-term durability and reliability in harsh conditions.
Cost Control
- Raw Material Costs: The cost of raw materials, especially nickel and chromium, is high.
- Production Efficiency: Improving production efficiency can reduce costs. This includes optimizing rolling and heat treatment processes, reducing waste, and improving material utilization.
- Scale of Production: Large-scale production can reduce unit costs due to economies of scale.
Production Flow
- Raw Material Preparation: Alloy materials are melted and cast into ingots.
- Hot Rolling: The ingots are hot-rolled into thicker plates or strips.
- Cold Rolling: The hot-rolled material is further cold-rolled to the desired thickness.
- Heat Treatment: The strips undergo heat treatment to optimize their microstructure and mechanical properties.
- Precision Finishing: Final finishing operations such as cutting, slitting, and surface treatment are performed.
- Quality Inspection: The strips undergo rigorous quality inspection to ensure they meet specified standards.
Incoloy 925 Bar Applications and Uses
Incoloy 925 Bar is widely used in the following applications:
- Petrochemical Industry: Components for oil well tubing, pipelines, valves, and refinery equipment.
- Marine Engineering: Parts for ships, submarines, and offshore platforms due to its excellent seawater corrosion resistance.
- Aerospace Industry: Components for engines, heat treatment equipment, and structural parts requiring high temperature stability.
- Chemical Industry: Reactors, heat exchangers, and steam generators.
- Nuclear Industry: Equipment in nuclear reactors due to its high corrosion resistance and mechanical properties.
Incoloy 925 Bars are used in a variety of demanding applications across multiple industries.
| Industry | Applications | Examples |
|---|---|---|
| Heat Treating | Furnace components, muffles. | Withstands extreme heat and oxidation. |
| Chemical Processing | Reactors, heat exchangers, piping. | Resists corrosive chemicals and high temperatures. |
| Power Generation | Boiler tubes, superheaters. | Provides durability in high-pressure and high-temperature environments. |
| Aerospace | Turbine blades, exhaust systems. | Used in jet engines for its high-temperature resistance. |
| Electronics | Heating elements, thermocouples. | Offers reliable performance in electronic applications. |
Alloy Factory
Huaxiao Metal Supplier provides professional services and reasonable prices, offering customers the best quality products. The Incoloy Alloy Bar Alloy Factory is a specialized manufacturing facility dedicated to the production of high-quality Incoloy alloy strips. This factory combines advanced technology, rigorous quality control, and experienced personnel to ensure the production of Incoloy alloy strips that meet the highest standards.The factory is equipped with state-of-the-art production equipment and machinery, capable of producing Incoloy alloy Bar with precise dimensions and consistent quality.Welcome to reqiure, and ask to the price.
Price Factors
The price of Inconel 925 Bar is influenced by several factors, including the market price of nickel (its primary component), the high production and processing costs, and demand from industries such as aerospace, energy, and chemicals. Prices can vary significantly based on order size, supplier, and market conditions.
Inconel 925 Bar is a versatile and high-performance alloy that plays a crucial role in numerous high-tech industries. Its unique combination of properties makes it an ideal material for applications requiring extreme durability and resistance to high temperatures and corrosive environments.
Incoloy 925 Bar is produced by various manufacturers worldwide, who employ advanced production processes and quality control measures to ensure consistent performance and quality. These factories can provide a range of specifications, including seamless tubes, steel plates, round bars, forgings, flanges, rings, welded tubes, steel strips, and wires. Customized production services are also available to meet specific customer requirements. Several alloy manufacturers specialize in producing Incoloy 925 bar, adhering to stringent standards to ensure quality and safety. These manufacturers often follow specifications such as ASTM B435, UNS N08330, and ISO 9453, ensuring the material’s traceability and consistency. Huaxiao Metal Supplier has the good price and quality in processing alloy.
In Conclusion
Incoloy 925 bars are a high-performance material designed for extreme environments. Their unique combination of chemical composition, physical properties, and mechanical strength makes them ideal for applications requiring resistance to high temperatures, oxidation, and corrosion. With a well-established manufacturing process, Incoloy 925 bars deliver reliability and longevity in critical industries. Incoloy 925 bar is a high-performance nickel-based alloy distinguished by its chemical composition, physical properties, mechanical properties, and numerous advantages. Its versatility makes it ideal for a wide range of applications in demanding environments, from petrochemicals to aerospace. The meticulous manufacturing process ensures consistent quality and reliability, making Incoloy 925 bar a trusted material choice for industries worldwide.
Incoloy 925 bars are a premium choice for applications requiring exceptional corrosion resistance and mechanical strength. Their ability to perform in a wide range of corrosive environments, combined with excellent fabricability and weldability, makes them indispensable in industries such as chemical processing, oil and gas, and marine engineering. The precise manufacturing process ensures that Incoloy 925 bars meet the highest quality standards, providing reliable performance in the most demanding environments. Huaxiao Metal Supplier has all kinds of alloy products, the delivery is fast, the service has the customerized solutions for every customers and clients.
Incoloy 925 bars offer a unique combination of high strength, excellent corrosion resistance, and good weldability, making them ideal for demanding applications in various industries. Their robust mechanical properties and versatility ensure long-term performance and reliability in harsh environments. Huaxiao Metal alloy products are good quality, Please contact us for any of your requirements.
