Incoloy 825 Strip nickel alloy, please note that the above table provides a range of standard thicknesses, widths, and lengths for Incoloy.
- Dimensions:
- Thickness: 0.3-200mm
- Width:<600mm,
- *Customized size needs to be confirmed with us
- Payment Term：L/C at sight, T/T, West Union ,
- Package：Export wooden pallets, Craft paper, Anti-Blushing Agent.
- Delivery Time: Future goods: Also 30 Work days, Ready Stock:7-15 days.
- Grades: 800, 800H, 800HT, 803, 825, 832, 864, 890, 903, 907, 908, 909, 925, 926, 945, 945X, MA956, A-286, 020, 028,DS, 330, 25-6HN, 27-7MO, X-750.
Incoloy 825 Strip Size And Specifications
The mechanical properties of Incoloy 825 strip are essential for its durability and performance in demanding environments. These properties include:
- High Ductility and Toughness: Ability to absorb energy and resist damage under external forces
- Good Creep Resistance: Maintains mechanical properties at elevated temperatures with minimal deformation
Incoloy 825 Strip is a nickel-based high-temperature alloy strip widely used in high-temperature and corrosive environments, particularly suitable for high-temperature equipment in the petrochemical, power, metallurgical, and aerospace industries. Huaxiao Metal Supplier provides all sizes of incoloy alloy strip for sale. Customized specifications are available upon request. Additionally, the exact chemical composition and mechanical properties may vary slightly within the ranges listed, depending on the specific alloy formulation and production process. Custom sizes are also available upon request.
Incoloy 825 strip, a nickel-iron-chromium alloy, bears distinct production codes according to various national standards. In the United States, it conforms to ASTM and ASME specifications, carrying the UNS number N08825 and is also known by the trade name Nickelvac 825. In Germany, the material is designated as W.Nr. 2.4858 and is referred to as Nicrofer 4241. In the United Kingdom, Incoloy 825 strip complies with BS standards and is identified as NA16. Within the International Organization for Standardization (ISO), it holds the number NiCr15Fe8.
These standards guarantee the uniformity of quality and performance of Incoloy 825 strip worldwide, making it a preferred material for applications in high-temperature and highly corrosive environments, such as in the oil, chemical, and marine industries. Welcome to inquire and ask for the lastest price, and learn about more details about the alloy strips. As a leading supplier & manufacturer in China, Huaxiao Metal supply cost-effective Incoloy 825 Products.
Incoloy 825 Strip Chemical Composition
| Element | Range (%) |
|---|---|
| Nickel (Ni) | 38~46 |
| Chromium (Cr) | 19.5~23.5 |
| Iron (Fe) | Balance (typically 22~26 as the base element) |
| Molybdenum (Mo) | 2.5~3.5 |
| Copper (Cu) | 1.5~3.0 |
| Carbon (C) | ≤0.025 (some sources state ≤0.03) |
| Manganese (Mn) | ≤1.0 |
| Silicon (Si) | ≤0.5 |
| Aluminum (Al) | ≤0.2 |
| Titanium (Ti) | 0.6~1.2 |
| Phosphorus (P) | ≤0.03 |
| Sulfur (S) | ≤0.03 |
| Cobalt (Co) | ≤1.0 (in some specifications) |
Huaxiao Metal Manufacturer is the professional and experienced in processing incoloy alloy strip in China.
Incoloy 825 Strip Physical Properties
| Property | Value |
|---|---|
| Density | 8.14 g/cm³ |
| Melting Point | 1370-1400°C |
| Thermal Expansion Coefficient | 14.0 µm/m°C (20-100°C) |
| Thermal Conductivity | 11.1 W/m·K (100°C) |
| Electrical Resistivity | 1.12 µΩ·m (20°C) |
The physical properties of Incoloy 825 strip make it suitable for various high-temperature and corrosive environments:
- Density: Approximately 8.14 g/cm³
- Melting Point: Between 1370~1400°C
- Thermal Expansion Coefficient: Approximately 13.3 × 10⁻⁶/°C
- Thermal Conductivity: Around 11.1 W/(m·K) or 13.1 W/(m·K) (varying sources)
Incoloy 825 Strip Nickel Alloy Mechanical Properties
| Property | Value |
|---|---|
| Tensile Strength | 586 MPa (min) |
| Yield Strength | 241 MPa (min) |
| Elongation | 30% (min) |
| Hardness | 200 HB (max) |
Incoloy 825 strip exhibits outstanding mechanical properties, which are crucial for its application in demanding environments:
- Tensile Strength (Rm): Typically 550 MPa, but can range up to 750 MPa depending on heat treatment
- Yield Strength (RP0.2): Approximately 220 MPa, with higher values possible after heat treatment
- Elongation (A5): Generally reaches about 30%, indicating good ductility and formability
- Brinell Hardness (HB): Approximately 160, though hardness may vary with heat treatment
- At elevated temperatures (e.g., 800°C), tensile and yield strengths remain high at ≥690 MPa and ≥275 MPa, respectively
Huaxiao Metal Manufacturer also provides other shapes of Incoloy products, such as coil, plate&sheet, wire&mesh, tube&pipe, bar. The price is affordable and suitable. Welcome to inqiure and learn more details about incoloy.
Incoloy 825 strip is a highly corrosion-resistant nickel-iron-chromium alloy with excellent performance in both oxidizing and reducing environments. Its optimized manufacturing process and cost-control measures ensure high-quality production at competitive costs. This material is ideal for demanding applications in chemical processing, oil and gas, and marine industries, where reliability and performance under corrosive conditions are critical.
Inconel 825 Strip is typically produced through sophisticated melting and casting processes, followed by heat treatment, forging, rolling, and other forming operations to achieve the desired microstructure and properties. Surface treatment processes may also be applied to further enhance its performance in specific applications.
Furthermore, Incoloy 825 strip possesses excellent ductility, allowing it to be formed and shaped into various configurations without cracking or breaking. These mechanical properties, combined with its corrosion resistance and high-temperature stability, make Incoloy 825 strip an ideal choice for applications in harsh environments such as the oil and gas, chemical, and nuclear industries. Huaxiao Metal Manufacturer is the professional and experienced in processing alloy in China, which has the good services and fast delivery in transportation.
What are the Nickel Alloy Benefits?
Incoloy 825 strip, ensuring its suitability for high-temperature and corrosive environments. The material is widely used in industries such as chemical processing, power generation, and heat treatment due to its excellent oxidation resistance, carburization resistance, and thermal stability. Compliance with these standards guarantees consistent quality and performance across global applications.It is resistant to a variety of corrosive media, including those containing sulfur and chlorine, at high temperatures and pressures. Welcome to Huaxiao Metal Manufacturer to request the price, trust you can be satisfied in the alloy Premium incoloy products and other alloy in China.
Incoloy 825 Strip Manufacturing Considerations
Huaxiao Metal Supplier provides all kinds of incoloy alloy coils in the world. Welcome to inquiry.
Producing Incoloy 825 strips involves several critical steps to ensure quality and performance.
Cost Control and Production Flow Considerations
- Material Costs: The cost of raw materials, particularly nickel, is a significant factor in the overall cost of Incoloy 825 strip. Fluctuations in nickel prices directly impact production costs.
- Processing Efficiency: Optimizing production processes, such as reducing waste during rolling and annealing, can help control costs.
- Yield Management: Improving yield by minimizing defects and scrap during manufacturing increases productivity and reduces cost per unit.
- Scale of Production: Larger production volumes can benefit from economies of scale, reducing unit costs.
- Market Demand: Fluctuations in market demand affect pricing strategies. High demand may justify higher prices, while low demand may necessitate cost-cutting measures.
The production of Incoloy 825 strip involves several key steps:
- Raw Material Selection: Precisely proportioned raw materials, including nickel, chromium, iron, molybdenum, and copper, are selected based on the desired alloy composition.
- Melting and Refining: The raw materials are melted in an electric furnace and refined to remove impurities, gases, and excess carbon, ensuring high alloy purity.
- Casting and Hot Rolling: The molten alloy is cast into ingots, which are then hot-rolled into strips of the desired thickness.
- Cold Rolling and Annealing: Further processing may involve cold rolling to achieve the final dimensions and annealing to relieve stresses and improve ductility.
- Surface Treatment: Processes such as pickling, polishing, or coating may be applied to enhance the strip’s surface finish and corrosion resistance.
- Inspection and Testing: Finally, the strip undergoes rigorous inspection and testing to ensure compliance with specified chemical, physical, and mechanical properties.
Incoloy 825 Strip Advantages
Incoloy 825 strip is renowned for its exceptional characteristics and advantages:
- Excellent Corrosion Resistance: Incoloy 825 strip demonstrates high resistance to a wide range of corrosive media, including sulfuric acid, phosphoric acid, nitric acid, organic acids, and alkalies like sodium hydroxide and potassium hydroxide. It is particularly resistant to chloride-induced corrosion, such as pitting, crevice corrosion, and stress corrosion cracking.
- Good Mechanical Properties: Its combination of high tensile strength, yield strength, ductility, and hardness makes it suitable for applications requiring both strength and formability.
- High Temperature Stability: The alloy maintains its mechanical properties and corrosion resistance at temperatures up to 550°C.
- Weldability: Incoloy 825 strip can be welded using various traditional welding methods, such as TIG, MIG, and SMAW, with good welding performance.
| Advantage | Description |
|---|---|
| High-Temperature Resistance | Maintains strength and resists oxidation at high temperatures. |
| Excellent Corrosion Resistance | Resists a wide range of corrosive environments, including acids, alkalis, and chlorides. |
| Versatility in Fabrication | Easily formed and welded, allowing for versatile use in various applications. |
| Mechanical Properties | High strength and ductility, suitable for high-stress applications. |
| Longevity and Durability | Long service life and low maintenance requirements, reducing downtime and costs. |
| Cost-Effectiveness | Reduced replacement costs and efficient manufacturing processes. |
Incoloy 825 Strip Applications and Uses
Incoloy 825 strip finds widespread application in various industries due to its superior properties.
Due to its outstanding combination of high-temperature performance, corrosion resistance, and mechanical properties, Inconel 825 is widely used in:
Chemical Processing: Reactors, heat exchangers, and piping systems.
Power Generation: Heat exchangers, superheater tubes, and boiler components.
Heat Treatment: Furnace components, trays, and fixtures.
Oil and Gas: Downhole tubing and piping for corrosive environments.
Petrochemical: Equipment exposed to high temperatures and corrosive gases.
Incoloy 825 strips are used in a variety of demanding applications across multiple industries.
| Industry | Applications | Examples |
|---|---|---|
| Heat Treating | Furnace components, muffles. | Withstands extreme heat and oxidation. |
| Chemical Processing | Reactors, heat exchangers, piping. | Resists corrosive chemicals and high temperatures. |
| Power Generation | Boiler tubes, superheaters. | Provides durability in high-pressure and high-temperature environments. |
| Aerospace | Turbine blades, exhaust systems. | Used in jet engines for its high-temperature resistance. |
| Electronics | Heating elements, thermocouples. | Offers reliable performance in electronic applications. |
Alloy Factory
Huaxiao Metal Supplier provides professional services and reasonable prices, offering customers the best quality products. The Incoloy Alloy Strip Alloy Factory is a specialized manufacturing facility dedicated to the production of high-quality Incoloy alloy strips. This factory combines advanced technology, rigorous quality control, and experienced personnel to ensure the production of Incoloy alloy strips that meet the highest standards.The factory is equipped with state-of-the-art production equipment and machinery, capable of producing Incoloy alloy strip with precise dimensions and consistent quality.Welcome to reqiure, and ask to the price.
Incoloy 825 strip is a versatile nickel-based alloy with a well-balanced combination of chemical composition, physical properties, mechanical properties, and corrosion resistance. Its manufacturing process involves precise control at each step to ensure consistent quality and performance. Cost control measures are implemented throughout the production flow to maintain competitiveness in the market.
Incoloy 825 strip is produced by various manufacturers worldwide, who employ advanced production processes and quality control measures to ensure consistent performance and quality. These factories can provide a range of specifications, including seamless tubes, steel plates, round bars, forgings, flanges, rings, welded tubes, steel strips, and wires. Customized production services are also available to meet specific customer requirements. Several alloy manufacturers specialize in producing Incoloy 825 strip, adhering to stringent standards to ensure quality and safety. These manufacturers often follow specifications such as ASTM B435, UNS N08330, and ISO 9453, ensuring the material’s traceability and consistency.
In Conclusion
Incoloy 825 strip is a versatile nickel-iron-chromium alloy with excellent high-temperature resistance, oxidation resistance, and corrosion resistance. Its optimized manufacturing process and cost-control measures ensure high-quality production at competitive costs. This material is ideal for demanding applications in chemical processing, power generation, and heat treatment industries, where reliability and performance under extreme conditions are critical.Huaxiao Metal alloy products are good quality, Please contact us for any of your requirements.
Incoloy 825 strip is a nickel-based high-temperature alloy with excellent high-temperature performance, corrosion resistance, and mechanical properties. It is widely used in various industries due to its comprehensive advantages. By optimizing manufacturing processes and controlling costs, Incoloy 825 strip can provide longer service life and better operational stability for equipment in high-temperature and high-corrosion environments. Huaxiao Metal Supplier has all kinds of alloy, the delivery is fast, the service has the customerized solutions.
